Double Sheet Thermoforming Pallet
Double Sheet Thermoforming Pallet( Also known as twin sheet thermoforming pallet, double sheet vacuum forming pallet, twin sheet vacuum forming pallet, thermoform plastic pallet, Plastic vacuum formed pallet, Double Layer Thermoplastic pallet ）
Plastic thermoforming pallet has very low weight, making it easier to lift and handle safety. As thermoplastic pallet is reusable and recylable, it is more environmentally friendly. Wood pallets must be heat treated and fumigated, vacuum formed pallet can avoid these expensive steps.
Share This Page
Advantage
- Steel pipe can be thermoformed directly into the pallet to get super high load capacity.
- The double sheet can be in different thickness, the bottom sheet is thicker and top sheet is thinner, which can ensure high strength while keep the weight lower, it’s more cost effective than blow molding pallet.
- Thermoforming pallet has better tough comparing to injection molding pallet. It’s very hard to smash
- Super long service life: up to 10 years.
- Lower operation costs than wood pallet.
- Shock resistance, resistance to the forklist fork impact
- Drop resistance, won’t damage from 5m high fall, 5 times better than national standard.
- Low temperature resistance: in -40℃ temperature , the performance remains the same.
- Tear resistance: the broken area wouldn’t extend.
- The pallet can be in multi-color, personalized customization, make pallet only belong to you.
- Intelligent : integrate with RFID, GPS, GPRS, RTIF and other intelligent modules.
Why We Have Best Cost Performance
- One step fully automatic extrusion and twin sheet thermofoming technology, very low cost.
- Unique formula, three times serivice life than wood pallet and normal plastic pallet.
- Can be repared as tire, low maintenance cost.
Three Runners Pallet
Wide application range
Three runners pallet suitable for majority working conditions, it is a pallet with strong versatility. The pallet can be used with forklift, pallet truck, all kinds of shelves, pallet conveyor, wrapping machine, packing belt and goods stacking equipment.
Non-Slip design
Zhanshi pallet has anti-skid surface, and anti skid pads are installed according to usage. According to the anti-slip requirement of goods, anti-slip between empty pallet, anti-slip between pallet and forklift, and anti-slip between pallet and ground, there are 8 anti-slip pad positions on the pallet panel, fully improve the anti-slip performance of the pallet.
Humanization design
Reserve grip postion for operators, convenient for handling
Loading Strengthening
Up to 10 steel pipes can be thermoformed directly into the pallet to provide extra load strength
Parameters
| Dimensions | 1200*1000*150mm | 1200*1200*150mm | 1300*1100*155mm |
| Raw Material | HDPE | ||
| Working Temperature | -40℃ ~ 70℃ | ||
| Surface | Plane | ||
| Foot | 3 Runners | ||
| Production Process | Thin Sheet Thermoforming & Hot Melting | ||
| Anti-slip pad | 20 pcs | ||
| Steel Pipe Quantity | 4pcs, 7pcs, 10pcs | 0, 4pcs, 7pcs , 10pcs | 7pcs , 9 pcs |
| Weight | 15kg , 17kg , 19kg | 12.6kg, 15.5kg, 17.5kg, 19.8kg | 20.6kg , 22.4kg |
| Static Load | 4.5T | 4.5T | 4.5T |
| Dynamic Load | 1.5T | 1T, 1T, 1.5T, 1.5T | 1.5T |
| Racked Load | 0.7T, 1T, 1.5T | NA , 500kg, 1T, 1.5T | 1T, 1.5T |
Nine Feet Pallet
Parameters
| Dimensions | 1200*1000*150mm | 1200*1000*150mm |
| Foot | Nine feet | |
| Production Process | Thin Sheet Thermoforming & Hot Melting | |
| Weight | 10kg | 8.2kg |
| Static Load | 4.5T | 4.5T |
| Dynamic Load | 1.5T | 1.5T |
Cross Base Pallet
Parameters
| Dimensions | 1200*1000*155mm | |
| Foot | Cross Base | |
| Production Process | Thin Sheet Thermoforming & Hot Melting | |
| Weight | 21.5kg | |
| Static Load | 4.5T | |
| Dynamic Load | 1.5T | |
Double Side Pallet
Parameters
| Dimensions | 1200*1000*170mm | |
| Foot | Double way/ Double Side | |
| Production Process | Thin Sheet Thermoforming & Hot Melting | |
| Steel Pipe Quantity | 8 | |
| Weight | 23kg | |
| Static Load | 4.5T | |
| Dynamic Load | 1.5T | |
| Racked Load | 1T | |
